Rapid Prototyping Platform

A flexible embedded platform that enables organizations to rapidly deploy, validate, and monitor applications in real time using simulation models and scalable I/O architectures.

Execute MATLAB/Simulink, SCADE, and ControlBuild models with minimal integration effort

Simplify deployment through automatic mapping between model variables and electrical signals

Scale from simple embedded applications to complex real-time systems with hundreds of I/O channels

Configure, monitor, and update systems through a cybersecure embedded web interface

Product Description

The Rapid Prototyping Platform enables organizations to quickly validate concepts, algorithms, and embedded applications using hardware designed for real-time operation. By combining simulation model integration, scalable I/O capabilities, and advanced visualization tools, the platform helps engineers accelerate development while reducing integration risk.

Supporting MATLAB/Simulink, SCADE, and ControlBuild models, the solution provides a seamless transition from simulation to deployment. Automatic signal mapping and ICD import capabilities simplify system integration and shorten development cycles.

Built on Averna Powered by Spherea's U-TEST® real-time Software-in-the-Loop (SIL) platform, it supports demanding embedded applications requiring deterministic performance, advanced monitoring, and secure remote access. The solution can be tailored from compact prototyping environments to large-scale operational systems supporting hundreds of signals.

Key Benefits

Reduce development time by deploying simulation models directly onto embedded hardware

Accelerate integration through automatic signal mapping and ICD import

Scale from prototype systems to complex real-time applications

Improve operational visibility through customizable dashboards and monitoring tools

Securely configure and update systems through a web-based interface

Validate concepts faster while reducing development and deployment risks

Application Areas

Aerospace

Defense

Railway

automated test expertise for the automotive and transportation industry including EV

Automotive & Transportation

automated test expertise for the power and energy industry including smart grid

Power & Energy

Laboratory employee with blood samples in test ampoules

Life sciences

Consumer Electronics

Prototyping

Execute MATLAB/Simulink, SCADE, and ControlBuild models developed by customers
Reduce software redevelopment and manual integration effort
Accelerate the transition from system design to deployment

Automatically map model variables to real-world electrical signals
Simplify system configuration and commissioning
Reduce engineering effort while improving consistency

Support both simple and highly complex embedded applications
Accomodates a small number of inputs and outputs to hundreds of I/O channels
Support demanding applications with up to 640 digital I/Os, 320 analog I/Os, 240 ARINC 429 Tx/Rx interfaces, 32 CAN interfaces, and 12 AFDX (Ethernet) interfaces
Tailor the hardware architecture to meet specific performance, connectivity, and operational requirements
Expand system capabilities over time while maintaining a consistent development and deployment environment

Configure systems through a browser-based environment
Update models without requiring local access
Monitor inputs, outputs, and operational status in real time
Access and review recorded system data for troubleshooting and analysis

Create custom dashboards and graphical applications
Monitor multiple devices simultaneously
Build user-defined visual environments tailored to operational needs
Improve decision-making through real-time system visibility

Built using U-TEST SIL for demanding real-time applications
Supports up to 1200 I/O channels with refresh rates as low as 2 milliseconds
Delivers deterministic performance for mission-critical systems
Supports aerospace and railway certification requirements

Supported Models: MATLAB/Simulink, SCADE, ControlBuild
Signal Intergration: Automatic variable-to-I/O mapping
ICD Support: Automatic ICD import
Monitoring Interface: Cybersecure embedded web interface
Visualization: User-configurable dashboards and applications
Scalability: Simple: 3 input and 2 guided contact outputs, 2 Ethernet buses, 1 4G/LTE modem, 1 IMU

Complex: 640 digital I/Os, 320 analog I/Os, 240 ARINC 429 Tx/Rx interfaces, 32 CAN interfaces, and 12 AFDX (ETH) interfaces
Real-Time Performance: Up to 1200 I/Os with 2 ms refresh rate
Foundation Technology: U-TEST real-time platform
Certifications: Aerospace (DO-160) and Railway (EN 50155) compatible
Communication Interfaces: Ethernet, LTE, CAN, ARINC 429 and configurable I/O options
