      RF SPECIFICATIONS
      Frequency
      Input Frequency 5 MHz to 1.8 GHz
      Resolution 10 Hz
      Phase Noise (1 GHz @ 10 kHz offset) < -110 dBc/Hz, 10 kHz offset
      Internal Reference 10 MHz
        +/-1 ppm/year aging
      Temperature Stability +/- 1 ppm (max.)
      Amplitude
      Noise Floor -164 dBm/Hz
      Noise Figure 10 dB
      Maximum Input 15 dBm
      Baseband
      Real-time Bandwidth 200 MHz per card
      Sample Rate 245.76 MS/s (DS DOCSIS 3.0)
        204.8 MS/s (US DOCSIS 3.0)
        256 MS/s (DS/US DOCSIS 3.1)
      Dynamic Range 70 dB
      SFDR 90 dB
      Output Resolution 16-bit
      CONNECTIVITY
      RF Connectors
      RF Inputs (75Ω) 2 x Type F female
      10.24 MHz Reference
      10.24 MHz REF Input (50Ω) 1 x SMA female
      10.24 MHz REF Output (50Ω) 1 x SMA female
      Triggering
      Input (50Ω) 1 x SMA female
        Level: TTL 5V TOL, Max.: -0.5/5.5V
      Output (50Ω) 1 x SMA female
        Level: TTL 5V
      Synchronization
      Input (50Ω) 1 x SMA female
        Level: TTL 5V TOL, Max.: -0.5/5.5V
      Output (50Ω) 1 x SMA female
        Level: TTL 5V
      Ethernet
      1 x 10/100/1000 Mbps RJ-45 LAN port
      Peripherals
      4 x USB 3.0 Type A peripheral ports (back)
      2 x USB 2.0/1.1 Type A peripheral ports (back)
      Storage
      Internal: 4 x 2.5” 256 GB SSD
      External: RAID PCIe connector
      Display
      1 x VGA port
      Compliance
      FCC 47 Part 15 Class A
      European Directive 98/336/EEC Class A (Emissions)
      European Directive 2002/95/EC (WEEE)
      GENERAL
      Weight
      27 kg (59.52 lbs)
      Size
      Unit 4 U
      Rackmount 48 cm (19 in)
      Deep 61 cm (24 in)
      Temperature
      Operating 0˚C (32˚F) to 35˚C (95˚F)
      Storage -20˚C (-4˚F) to 70˚C (158˚F)
      Relative Humidity
      10% to 90% (non-condensing)
      Power*
      90-264 VAC
      50/60 Hz
      400 watts (typ.)

      Specifications are subject to change without notice.
      *IEC 60320-C14 power connector inlet
      IEC 60320-C13 to NEMA 5-15P, 3 m (9.8 ft) North American power cord included
      IEC 60320-C13 to CEE 7/7, 3 m (9.8 ft) European power cord included
      Rackmount brackets included
